CVW 3700 | HBW 3700 | CW 3700 | EW 3700 | VW 3700 | HW 3700 | FW 3700 | Adapters & Inserts | Hardware & Screen



The industry standard and our most popular window, this is a project-out, conventional-style model. It is available with manual or rotary operation.

3700 Series Windows VW3700
Application
Conventional Frame
Frame Joints
Screw-spline
Window Joints
Mitered-clip, Epoxy & Stake
Glass Thickness
1/4" & 1"
Face Width
2-3/8"
Frame Depth
2"
Hardware
HD Stainless Steal
Clear or Black manual cam locks
Optional Hardware
Roto Operated, Custodial Locks,
Pole Handles, Limit Stops
Air Infiltration
<.01CFM/Ft2
Static Water
12 PSF
AAMA/WDMA/CSA 101 I.5.2/A440-08,
NAFS Testing
Class CW-PG-75
Life Cycle Tested
2500 Cycles
U-Factor
.47
Screen

VW Conventional
CAD File (DWG):
Details:
Installation Instructions:
Test Reports:
Specs:
ZIP File
PDF File
E3700
E3701
E3702
E3703
E3710
E3720
PDF File
PDF File
Text File
